A flexible PCB or FPCB is a speckled preparation of printed circuitry and components that uses flexible based material with or without flexible coverlay. Such flexible electronic assemblies may be easily fabricated using the same components used for rigid printed circuit boards but enabling the board to fit to a desired shape.
Flexible PCB / FPCB Applications
As far as quick turn rigid flex PCBs applications are concerned, they are widely used in everyday technology and electronics in addition to high-end, complex completed components. Flexible circuits are widely used in modern portable electronics, devices, hard disk drives and desktop printers. FPCB circuits are also used broadly in other applications and industries including aerospace, medical, automotive, military, communications, transportation, consumer electronics, wearables, industrial and many more.
Quick turn rigid flex PCB manufacturer uses quite a simple process in its manufacturing. Preparation of design is the most important process as PCB data is sent by the designer to the producer in file format through email. Depending upon your needs, they can offer flexible and rigid-flex PCB from prototype to small batch production.
Benefits of Quick Turn Rigid-Flex PCB
Because of the quick-turn process, the clients will easily receive their printed circuit board on time. In today’s world of ever-evolving electronic technology, quick turn rigid flex PCB are a great choice for a number of good reasons in addition to their usefulness.
Advantages this board will offer to the users include:
Great Flexibility – The elastic nature of the flex PCB allows placement around edges and folds. The flexible nature of this board is used in electronic devices that need 3 axes connections. As very little or no wiring is needed, it easily eliminates wire connection failure and increases the reliability of the device.
Save Space and Weight – Another benefit of flex PCB is that it saves up to 60% of the weight and space compared to Rigid PCB or wire harness applications.
Act Anti-Vibration - Added flexibility and lighter weights enable the flex circuits to absorb and reduce the impact of the vibration to itself as well as any solder joints in connections.
Highly Effective in Harsh Environment – Flex circuits are best built with materials that are best suitable to use in harsh operating environments. The materials such FCBs are made comprise certain properties like waterproof, moisture proof, shock proof, high temperature oil, and corrosion resistant.
Circuit Board Variety - The PCB manufacturers strive to meet all customers’ PCB needs because they are aware that each customer has distinct requirements. Thus, they provide a wide range of PCBs to meet their needs. Get a flexible PCB quote to know about the benefits that you will avail in advance.
So, if your product needs a board that needs to be folded when assembled or you’re after something highly durable and long-lasting then a Quick Turn Rigid Flex PCB might be the right fit for you.
